Main Specifications
1xN PLC Splitters Modules
|
Type & Parameters |
1x2 |
1x4 |
1x6 |
1x8 |
1x12 |
1x16 |
1x24 |
1x32 |
1x64 |
||
|
Insertion Loss (dB)1,2 |
With connector |
Max |
4.1 |
7.4 |
9.2 |
10.5 |
12.4 |
13.8 |
15.5 |
17.1 |
20.4 |
|
Typ |
4.0 |
7.0 |
8.8 |
10.0 |
11.8 |
13.1 |
14.9 |
16.2 |
19.5 |
||
|
PDL (dB) 1,2 |
Max |
0.15 |
0.2 |
0.2 |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
|
|
Loss Uniformity(dB) 1,2 |
Max |
0.6 |
0.7 |
0.7 |
0.8 |
1.0 |
1.0 |
1.2 |
1.5 |
2.0 |
|
|
Operating Wavelength (nm) |
|
1260~1650 |
|||||||||
|
Return Loss (dB) 1,2 |
With APC |
Min |
55 |
||||||||
|
With UPC |
Min |
50 |
|||||||||
|
Directivity (dB) |
Min |
55 |
|||||||||
|
Fiber Type |
|
G657A1 or G657A2 or customer specify |
|||||||||
Notes:
1. Measured at room temperature
2. Measured at 1310nm and 1550nm
Pigtail And Connector
|
Fiber Type |
2mm cable or customer specify |
|
Fiber Length |
1.0m or customer specify |
|
Connector |
SC/UPC, SC/APC,FC/UPC or customer specify |
|
Item |
Specification |
Unit |
|
Operating temperature |
-40~85 |
°C |
|
Operation Humidity |
5-95 |
%RH |
|
Storage Temperature |
-40~85 |
°C |
|
Storage Humidity |
5-95 |
%RH |
