Items |
Parameters |
|||||||||||||||||||||
|
Transmission Distance |
Optical interface: SFP+, Distance depend on plug-in Optical Transceiver, such as MM 300m SM 20/40/60/80/120km |
|||||||||||||||||||||
|
Transmission Speed |
125Mb/s ~ 11.7G |
|||||||||||||||||||||
|
Protocols |
Transparent Transport |
|||||||||||||||||||||
|
Interface Type |
SFP+ To/From SFP+ |
|||||||||||||||||||||
|
LED Indicatiors |
SFP1, SFP2, LOOP, PWR |
|||||||||||||||||||||
|
DIP Switches |
*SW1 and SW2 are combination switches *SW3 and SW4 are combination switches |
|||||||||||||||||||||
|
Maximum Packet Forwarding Rate |
14,880,950/S |
|||||||||||||||||||||
|
Environmental Requirement |
Operating Temperature: 0℃~50℃ Storage Temperature: -10℃~70℃ Relative Humidity: 5%~90% (Non-condensation) |
|||||||||||||||||||||
|
Power SupplySpecificationsand Dimensions |
External Power, AC 100V-240V DC:5V~12V Power Consumption: Full-load<7W |
|||||||||||||||||||||
|
|
Power consumption≤2W (without module) |
|||||||||||||||||||||
|
Mechanical Structure |
Dimensions: 90mm(D)×60mm(W)×20mm(H) Weight: 130g |
|||||||||||||||||||||
|
MTBF |
50,000h |
|||||||||||||||||||||
|
Enclosure |
Metal |
|||||||||||||||||||||
|
Warranty |
1 Year |
|||||||||||||||||||||
|
Emissions |
FCC Class A, CE Class A |
Support Jumbo Frame
Transparent Transport and very low delay
Support ITU-T prescribed DWDM/CWDM wavelength
DIP switch to set different configurations
Supports LFP function, ALS function, Loopback function
Support hot plugging
LEDs Indicate Fiber Link Status at a Glance
Plug-and-play, Support 1U 12 Slots Chassis & Standalone Use
Easy installation
SM and MM interconversion, Wavelength conversion.
Optical signal regeneration and amplification.
Optical signal reshaping.
Technical Specifications
